Louis Poulsen AJ Eklipta Wall / Ceiling Light
100% Authentic Pieces
Price match. Found it cheaper? Contact us
Free delivery over £75 T&C's apply
Trade discount available
We're happy to help? Get in touch or chat now
Sign up for everyday special prices
Manufacturer: Louis Poulsen
Designer: Arne Jacobsen
Arne Jacobsen designed the fixture for the Rødovre Town Hall, situated in a suburb of Copenhagen in Denmark, in 1959. The AJ Eklipta is available as a surface lamp and a wall and ceiling lamp, which emits a pleasant glare-free light due to its lampshade made out of three layers of mouth-blown opal glass. Its translucent rim furthermore creates an atmospheric light halo around the fixture.
When using the fixture himself for example on stairways, Arne Jacobsen favoured the larger of the two sizes available at the time, namely the 450 mm. Later, he designed a 220 mm version specifically for St. Catherine’s College (Oxford University) in the UK. Today, all three sizes are used worldwide, in a variety of architectonic settings.
Materials: Ceiling/Wall box: Die cast aluminium or spun aluminium Shield: Mouth-blown white opal glass.
Mounting: Terminal block: Ø 220: 3x2,5mm², Ø 350/Ø 450: 5x2,5mm².
Looping: Approved, Ø 220: Max. 3x1,5mm², Ø 350mm/Ø 450: Max. 5x1,5mm². Ballast positioning: In ceiling/wall box.
Class: Ingress protection. LED ceiling/wall: IP20. Ø220: IP20. E27 Ø350/450 Ceiling: IP20. E27 Ø350/450 Wall: IP44. Electric shock protection I w. ground.
Lightsource required (not included) D22cm: x1 33W G9
D35cm: x1 60W E27
D45cm: x1 60W E27
Also available as LED versions, please contact one of our team for more information.
Dimensions:
220 Wall & Ceiling Light: Shield diameter: 220mm Box diameter: 83mm Projection: 105mm.
350 Wall Light: Shield diameter: 350mm Box diameter: 172mm Projection: 100mm.
